UT-XT

UTILITY TRAILERS

When it comes to hauling, easy loading and unloading matters. With our gravity tilt deck, you can get from loaded to unloaded by simply releasing both latches with a single handle. Load it with whatever you want with drive-over fenders and standard pine floor — or make it your own with a steel floor upgrade for even more style.

Available colors

Model GAWR GVWR Curb Wt. Payload Length
UT-21 XT 8,000 16,000 4,350 lbs 13,250 lbs

4’ stat. + 17’ tilt
UT-23 XT 8,000 16,000 4,450 lbs 13,150 lbs

4’ stat. + 19’ tilt

Always Included

  • Dexter 8K torsion axles

  • 17.5 H-rated tires/wheels

  • 8″ structural channel mainframe

  • 3” x 6” structural angle top-frame
  • 3” channel crossmember, 16” centers
  • Spring-assist ramps

  • Gravity split-deck tilt

  • Vertical ramp storage
  • 81” between fenders
  • 2”x3/8 rub rail, with stake pockets

  • All-axle electric brakes

  • Rubber-mounted LED lighting

  • Silicone-filled electrical connectors

  • Breakaway kit with 12-volt battery

  • Lockable toolbox

  • Spare tire bracket

  • 2 D-rings, front of deck

  • Treated and kiln-dried pine decking

  • Bead-blasted pre-paint

  • PPG epoxy primer and urethane paint

MAKE-IT-YOUR-OWN

  • 10K Dexter torsion axles (adds 550 lbs to curb weight)

  • Drive-over fenders with 102″ wide deck

  • 24″ dovetail

  • Wood-filled ramps

  • Full/split gates

  • Ladder/mesh ramps (5′ x 24″)

  • Pintle ring

  • Fork storage

  • Gooseneck
  • Oak floor
  • Steel floor (12″ on center crossmembers included)

  • Hydraulic-powered tilting deck

  • Add extra length to stationary deck

  • Extra 10K drop jack

  • Single hydraulic jack

  • Blackout Package (black wheels and black decals/stripes)

Curb weight is based on a standard model unit with no options.
**Payload is calculated on 10% transfer weight on bumper hitch when weight is distributed evenly.

*some pictures still show the last generation of logos and graphics, only the “new” logos/graphics are available
